The USRP-LW E310 is an advanced embedded Software-Defined Radio (SDR) platform. It features the AD9361 RF transceiver, which supports 2x2 MIMO and operates across a frequency range of 70 MHz to 6 GHz with an instantaneous bandwidth of up to 56 MHz. The device measures 133 x 68 x 26.4 mm and consumes only 2-6 watts of power, making it an ideal solution for mobile and embedded applications due to its lightweight, low-power, and compact design. Baseband processing is performed on a reconfigurable Zynq 7020 System-on-Chip (SoC), which integrates a Xilinx 7-series FPGA with a dual-core ARM A9 processor, running a Linux operating system. Like all USRP devices, it leverages an open-source software architecture that provides comprehensive cross-platform support and compatibility with the Universal Hardware Driver (UHD). This enables seamless integration with a wide range of applications and SDR frameworks, including GNU Radio.
USRP-LW E310
●
The maximum received signal bandwidth is 56M
●
The frequency covers 70 MHz - 6 GHz
●
12-bit ADC/DAC
●
Preselect the filter bank
●
Dual-core ARM Cortex A9-866 MHz processor, Xilinx Zynq 7020 SoC FPGA
●
1GB DDR3 RAM for ARM CPUs and 512 MB DDR3 RAM for FPGA Logic
●
Supports ARM processors with sampling rates up to 10MS/s
●
Ethernet and USB interface control
●
Built-in open source UHD3.9.2 and API interface
●
Built-in 9-axis inertial measurement unit
●
FPGA development framework that supports RFNoC
●
Stereo audio output and mono microphone input
●
Integrated global Positioning GPS receiver
●
Dimensions: 133 x 68 x 26.4 mm Weight: 375 g
●
Support GNU Radio
Product introduction
Technical parameter
Input/Output | RF Performance Parameters | ||
DC Voltage Input | 5-15V | RF Range | 70-6GHz |
Convert Module Parameters | Output Power | >10dBm | |
ADC Sampling Rate (Max) | 61.44 MSps | Noise Figure | <8dB |
ADC Resolution | 12 bits | Input of the third-order intercept point | -20dBm |
DAC Sampling Rate | 61.44 MSps | Physical Properties | |
DAC Resolution | 12 bits | Size | 13.3*6.8*2.6cm |
Maximum Tansfer Rate With Host (16b) | 61.44 MSps | Weight | 375g |
