The USRP-LW B205 Plus is a compact, industrial-grade Software-Defined Radio (SDR) platform. This device features an industrial-grade, programmable Xilinx Artix™ 7 XC7A 200T FPGA and utilizes ADI's AD9364 RF integrated circuit for its transmit front-end, making it a cost-effective 1T1R transceiver.
Luowave B205 plus
●
The radio frequency range covers 70MHz to 6GHz
●
The maximum supported real-time bandwidth is 56 MHz, with a reference sampling rate of 61.44 MSps
●
The open-source UHD supports multiple frameworks
●
Support for UHD 4.0 or newer driver versions is required.
●
Supports high-speed USB 3.0 connection and USB power supply.
●
GPIO general interface and JTAG debugging capabilities
●
Supports 10 MHz reference clock or PPS synchronization
●
Support for Xilinx VIVADO versions below 2019.2
Product introduction
Technical parameter
| Input/Output | RF Performance Parameters | ||
| DC Voltage Input | 5V | Input 3rd Order Intercept Point | -21dBm |
| Max Output Power | ＞10dBm | Noise Figure | ＜8.5dB |
| Conversion Module Parameters | |||
| ADC Sampling Rate (Max) | 61.44 MSps | LO Accuracy | ±2.0ppm |
| ADC Resolution | 12 bits | Size | 11×6.5×2 cm |
| DAC Sampling Rate | 61.44 MSps | Weight | 0.14kg |
| DAC Resolution | 12 bits | ||
| Max Rate with Host (16b) | 61.44 MSps | ||
